+1 (813) 649-889929W-60W Semi-Cutoff LED Wall Pack 3000K-5000K - 100-277VAC Photocell - Striped Glass - Bronze
Description
HTM Lighting Solutions Wattage Selectable & CCT Tunable Semi-Cutoff LED Wall Pack is available in 29W, 40W, and 60W all within the same fixture & a built-in Photocell!
3000K, 4000K, and 5000K CCT Tunable Switch enables the user to choose the color temperature best suitable for the application.
Manufactured using Die-Cast Aluminum, this durable LED Semi-Cutoff Wall Pack also comes with Striped Glass with 110 Degree Beam Angle to ensure reliability, and constant even light output throughout its longevity.
Features:
- 100-277VAC Rated w/ 4kV Built-in Surge Protector
- IP65 Rated for Wet Location
- Striped Glass Lens (No Yellowing)
- Power Selectable available in 29W, 40W, or 60W
- CCT Tunable in 3000K (Warm White), 4000K (Natural White), 5000K (Cool White)
- Photocell Integrated (Can be disconnected)
- 1/2" Knockouts for field-installed accessories such as a motion sensor
- UL Listed & DLC Premium# PMQNC9U4 for Federal & State Rebates
- 5-Year Limited Warranty
Ratings:
- 29W LED = 4,060lm (100W MH Equal) – 10-12ft Mounting Height
- 40W LED = 5,800lm (250W MH Equal) – 12-15ft Mounting Height
- 60W LED = 8,700lm (320W MH Equal) – 15-20ft Mounting Height
| Type | LED Wall Pack | ||
| Item Dimensions | 10.75in. x 7.6in. x 8.25in. | ||
| Wattage | 60W / 40W / 29W | ||
| Equivalent | 320W MH / 250W MH / 100W MH | ||
| CCT | 3000K / 4000K / 5000K | ||
| Lumens | 3,915 - 8,700 Lm | ||
| CRI | >80 | ||
| Input Voltage | 100-277VAC | ||
| Finish | Bronze |
| Material | Heavy-Duty Cast Aluminum |
| Rated Lifetime | 50,000+ Hours |
| Beam Angle | 110 Degrees |
| Lens Type | Tempered Stripe Glass |
| Mounting Type | Wall-Mount |
| IP Rating | IP65 for Wet Locations |
| Warranty | 5-Year Limited |
| Certification(s) |
|
Downloads
Download Datasheet
Download Instructions
Database of State Incentives
Watch Product Video×
| Box Qty | 1 |
| Box Dimensions (in.) | 12in. x 11in. x 11in. |
| Box Weight (lbs) | 7.05 Lbs |
| Carton Qty | 4 |
| Carton Dimensions (in.) | 23in. x 22in. x 14in. |
| Cartin Weight (lbs) | 30.85 lbs |
